MINI STEP MOTOR
The mini step motor features a rational permanent magnet (PM) design. In an open loop system the motor performs very reliably with good positioning precision and repeatability. When properly matched with driving electronics, various incremental steps can be achieved (half step, micro steps).
Typical applications
Security systems, office automation systems, medical equipment, mini household appliances, high-end hobby applications, etc.
MINI STEP MOTOR
The mini step motor features a rational permanent magnet (PM) design. In an open loop system the motor performs very reliably with good positioning precision and repeatability. When properly matched with driving electronics, various incremental steps can be achieved (half step, micro steps).
Typical applications
Security systems, office automation systems, medical equipment, mini household appliances, high-end hobby applications, etc.
Technical Data
| Sr. No. | Motor No. | Dia x Length (max) | Max. Torque | Page |
|---|---|---|---|---|
| 1 | 1011P0209 | 10.00 x 10.20 mm | 0.40 mNm | 4 |
| 2 | 1511P0209 | 15.00 x 11.60 mm | 1.00 mNm | 5 |
| 2 | 3515P0489 | 35.00 x 15.00 mm | 10.00 mNm | 6 |
Technical Data
| Sr. No. | Motor No. | Dia x Length (max) | Max. Torque | Page |
|---|---|---|---|---|
| 1 | 1011P0209 | 10.00 x 10.20 mm | 0.40 mNm | 4 |
| 2 | 1511P0209 | 15.00 x 11.60 mm | 1.00 mNm | 5 |
| 2 | 3515P0489 | 35.00 x 15.00 mm | 10.00 mNm | 6 |
